VHF Marine Handheld Transceiver

Product Description

VHF Marine Handheld Transceiver

Our company presents a wide range of VHF Marine Handheld Transceiver.  This transceiver is integrated with a flashing light that activates when the radio hits water. It is also designed with a large, easy to read LCD screen which offers a clear 2-digit channel number indication. In this VHF Marine Handheld Transceiver, we have completely eliminated the exposed metal charging points which ensures protection from water damage.

Features:

• Easy to change the volume level to capture the received message
• Comes with accurate weather alert
• Built tough with super strong aluminum alloy chassis

Features

• 128 channels to program operating parameters via PC utility software
• Channel, Name tag and VFO (Frequency) display modes selectable
• Comes with a rechargeable Li-Ion pack, quick stand-charger and high-performance whip antenna
• Ergonomically designed compact body 59.0W x 98.0H x 35.0D mm or 2.32W x 3.86H x 1.38D inches (w/o projections, approx.), weighs approx.227g or 8.01oz inclusive of battery pack and antenna
• 3 types of Scan functions (VFO/Memory channels/Priority), 50 CTCSS, 116 DCS and 4 Tone-burst tones
• Backlit, Dot Matrix LCD screen with alphanumeric name tag
• Microphone and speaker ports
• Includes FM radio receiver, Internal VOX, Voiceprompt in English, Remote-Kill/Stun/Waken, Analog scrambling, Voice Compounder, Narrow FM, Repeater-reverse, Auto-Power-OFF, Busy-Channel Lockout, Time-Out-Timer and more and more at No extra costs

Specifications:

General

• Frequency coverage
• (TX/RX)136.000-173.995MHz
• (RX only) 76-108MHz
• ModeF3E(16K0F3E / 11K0F3E / RX only WFM)
• Programmable channels 128 channels
• Frequency stability 2.5ppm
• Power supply requirement 7.4V DC+/-20% (negative ground)
• Current drain (Approx.)1400mA TX / 300mA receive at Max audio output / 70 mA squelched
• Usable temperature range 20+55 (-4-131 Degree F)
• Dimensions (Projections not included/approx.)59.0W 98.0H 35.0D mm or 2.32W 3.86H 1.38D inches
• Weight : approx.227g or 8.01oz inclusive of battery pack and antenna
• Transmitter (ETSI EN300 086 compliant)
• Output power Approx.5 / 2 / 0.5W
• Modulation system Variable reactance FM
• Spurious emissions Less than 36dB
• Max. frequency deviation +/-5kHz / +/-2.5kHz
• Receiver (ETSI EN300 086 compliant)
• Receive system Double conversion superheterodyne
• Intermediate frequencies 38.85MHZ
• Sensitivity(12dB SINAD Wide/Narrow)
• 12dB or better
• (0.25V/0.35V) or better
• Selectivity 6dB : 6dB : Wide 12kHz /Narrow 10kHz or more
• 60dB :Wide 30kHz / Narrow 24kHz or less
• Audio output power1000mW(8 / Max)
